TekTone NC365B Paging Transmitter

TekTone NC365B Paging Transmitter

$3,582.75 $5,378.63
Brand: TekToneReviews
You save $1,795.88 (33%)
Special order products normally take 10–14 business days to ship, depending on vendor availability.
  • Free US shipping on this item.
  • Special order: no returns without a manufacturer RMA. It ships from the manufacturer and lead times vary. If you cancel after your payment is captured (4 business days after the order is made), a 3% card processing fee is deducted. Wrong or defective items are always covered.
    Return terms: you pay shipping both ways, 3% card fee, 30% if opened
    • 30 daysfrom delivery to start a return
    • Shipping both waysto you and back to us, paid by you
    • 3% card feededucted from every refund
    • 30% open-box feeif the box has been opened
    • Special ordersno returns without a manufacturer RMA
    • Discontinued itemsnot returnable

    Wrong or defective items, and items damaged in transit with Package Protection, are always covered with no fees. Full return policy

  • Manufacturer's warranty from TekTone. Warranty
  • Volume order? Get a quote: chat with us, email us, or add it to your cart and download a PDF quote.
D Questions about this product? Daniel and the team reply fast, usually within minutes, Mon–Fri 8am–4pm ET. Chat with us now or email us.
Securing a whole building?

Answer a few questions and the free Site Planner picks the intercom, door access, locks, cameras and network for every floor, priced live.

 Plan my building free
More information View images
Reviews

Overview

The TekTone NC365B Paging Transmitter receives alphanumeric messages and patient call information from a TekTone nurse call or alert system over a serial interface and transmits them directly to staff pagers. It is pre-programmed for TekTone systems for plug-and-play setup and suits hospitals, assisted living and long-term care facilities that want calls to follow caregivers around the building.

Key features

  • Pre-programmed for use with TekTone systems
  • Approximately one-mile range in ideal conditions (actual coverage depends on the site; a site survey is recommended)
  • 9600 baud serial input to minimize bottlenecks, 1200 baud transmit
  • Two RS232 serial DB9 ports (Scope protocol and COMP2 protocol)
  • 8 dry contact inputs configured as normally open; input #8 sends a RANGE TEST to CAP code 400 using the included dummy plug
  • Includes a 1/4-wave BNC-terminated antenna
  • Optional BA365K Battery Backup Kit

Specifications

Frequency 457.55 MHz
Channel spacing 12.5 kHz
Output 2 W
Baud rate 9600 serial input; 1200 transmit
Power input 115 VAC, 0.8 A, 50/60 Hz
Operating voltage 13.8 VDC
Consumption Less than 50 mA standby; up to 2.4 A transmit
Housing Surface mounted
Dimensions 7.48" H x 12.99" W x 2.76" D (190 x 330 x 70 mm)
Clearance 7.87" (200 mm) minimum on all sides

Typical uses

  • Sending nurse call alerts to NC397A pocket pagers in Tek-CARE nurse call systems
  • Paging staff from Tek-ALERT alert integration systems
  • Extending call annunciation across large care facilities

Shipping

Free US shipping on orders over $200. Orders under $200 ship at the rate shown at checkout. Oversized items ship by freight; we confirm the quote with you first.

Shipping policy

Returns

Special order: no returns without a manufacturer RMA. Wrong or defective items are always covered.

Start a return

Damaged or wrong item?

Tell us within 3 days of delivery with photos and we'll make it right, with no fee.

Contact us

TekTone warranty

This product is covered by the manufacturer's warranty. We help you with the claim from start to finish.

Warranty details

Support from real people

Setup questions, compatibility, firmware: chat with a specialist or email info@silarius.com, Monday to Friday, 8am to 4pm ET.

Chat with us

Business accounts

Approved businesses can pay on Net 30 / PO terms after their second completed order.

Ask about terms

Frequently Asked Questions

Which systems does the NC365B work with?+
TekTone lists the Tek-CARE 3000, Tek-CARE 400 GEN3, 400 P5/P5+, 400, NC300II, 120, NC110/150/200 (with an NC377-series Paging Interface Adapter), Tek-CARE 500 Wireless, Tek-ALERT and the NC475 Tek-CARE Appliance Server. NC397A pagers are required.
What range does the NC365B cover?+
Under ideal conditions the range is approximately one mile. Actual coverage depends on the site and transmitter location, so TekTone recommends a site survey.
Is an FCC license needed?+
Yes. TekTone states that each paging system installed in the United States is required by law to have an FCC license, which the end user or an authorized agent can obtain.
How is it powered?+
It takes 115 VAC, 0.8 A, 50/60 Hz input and operates at 13.8 VDC. An optional BA365K Battery Backup Kit is available.
Does it replace the nurse call system's own annunciation?+
No. TekTone notes paging is an ancillary method of call annunciation and is not intended to replace the primary annunciation of the nurse call system.
